Soft Flexible LED Display

Ultra-thin, ultra-lightweight, flexible LED display module is more flexible to design shapes and effects in any type and arc at any angles. With frequent curving, it will not break the LED lights as well as the design of the mask covers. At present, 240x120mm series, 320x160mm series and 256x128mm series are available. Contact us for more information
Pixel Pitch | P1.56 | P1.667 | P1.875 | P2 (240x120) | P2 (256x128) | P2.5 (240x120) | P2.5 (320x160) | P3 | P3.076 | P4 (240x120) | P4 (256X128) |
Pixel Configuration | SMD1010 | SMD1010 | SMD1010 | SMD1515 | SMD1515 | SMD1515 | SMD1515 | SMD2020 | SMD2020 | SMD2020 | SMD2020 |
Density (Pixels/㎡) | 410913 | 359856 | 284444 | 250000 | 249999 | 160000 | 160000 | 111111 | 105689 | 62500 | 62500 |
Module Resolution (Pixel) | 160x80 | 144x72 | 128x64 | 120x60 | 128x64 | 96x48 | 128x64 | 80x40 | 104x52 | 60x30 | 64x32 |
Module Size (mm) | 250x125 | 240x120 | 240x120 | 240x120 | 256x128 | 240x120 | 320x160 | 240x120 | 320x160 | 240x120 | 256x128 |
Driving Mode (Duty) | 1940-01-01 00:00:00 | 1936-01-01 00:00:00 | 1932-01-01 00:00:00 | 1930-01-01 00:00:00 | 1932-01-01 00:00:00 | 2024-01-01 00:00:00 | 1932-01-01 00:00:00 | 2020-01-01 00:00:00 | 2026-01-01 00:00:00 | 2015-01-01 00:00:00 | 2016-01-01 00:00:00 |
Brightness (CD/㎡) | ≥800 | ≥800 | ≥1,000 | ≥1,000 | ≥1,000 | ≥800 | ≥800 | ≥1,000 | ≥800 | ≥700 | ≥1,000 |
Viewing Angle (°) | 120 | ||||||||||
Gray Grade (Bits) | 14 | ||||||||||
Operation Power | AC100-240V 50-60Hz | ||||||||||
Max. Power Consumption (W/㎡) | 15 | 15 | 15 | 15 | 20 | 10 | 20 | 10 | 20 | 9 | 15 |
Frame Frequency (Hz) | ≥60 | ||||||||||
Refresh Frequency (Hz) | ≥3,840 | ||||||||||
Working Temperature (ºC) | -20~+60 | ||||||||||
Lifetime (Hours) | 100000 | ||||||||||
Protecting Grade | IP31 |
